Diversion Outlet

Water exiting the channel flows back into the Red River.

blank blank

Rush and Lower Rush River Inlets

Water from surrounding drainage areas that enter the Diversion Channel.

blank blank

Maple River Aqueduct & Spillway

A structure that allows the Maple River to cross over the Diversion Channel without entering it.

blank blank

Sheyenne River Aqueduct & Spillway

A structure that allows the Sheyenne River to cross over the Diversion Channel without entering it.

blank blank

Diversion Inlet & Control Structure

During times of extreme flooding, water behind the Southern Embankment will enter the Diversion Channel through the Inlet Control Structure.

blank blank

Wild Rice River and Red River Control Structures

Control structures allow the river to flow at a set height.

blank blank

Southern Embankment

The southern embankment is an earthen structure that temporarily holds water during extreme flood events.
